RL transient practice problems
Refresh the page to get a new problem.
Read the RL-transient class notes.
For the circuit shown,
- R = 270 Ω
- L = 680 μH
For the RL circuit, the source has been at an initial current value of Ii = -100 μA for a long time.
At t = 0, the source current abruptly jumps to If = 1.5 mA.
Determine the expression for the inductor current as a function of time, for t > 0.
Calculate the time when the inductor current will be equal to 0.967 mA and calculate the inductor voltage at that time.
